Name: Compact SMF 100G QSFP + Optical Transceiver 100G / ps AQSFP-100G-LR4 10KM
Brand: Ascent Optics Co.,Ltd.
SKU: 100G-QSFP-LR4-A
Price: Negotiable USD
Availability: InStock

Home Products 100G QSFP28 Transceiver

Compact SMF 100G QSFP + Optical Transceiver 100G / ps AQSFP-100G-LR4 10KM

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	AscentOptics/Neuter, OEM
Certification:	CE/FCC/RoHS/TUV/UL
Model Number:	100G-QSFP-LR4-A

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	10 or 20PCS /Plastic tray, 1PC/Gift box
Delivery Time:	Within 1-3 working days after PO confirmed
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	50,000pcs/Month

Contact Now

Detailed Product Description

Product Name:	QSFP + Optical Transceiver	Datarate:	100G/ps
Distance:	10KM	Wavelenth:	4 CWDM Lane 1270 1290 1310 1330
Application:	100G Ethernet/ 100G Infiniband	DDM/DOM:	YES
Highlight:	cisco sfp transceivers , fiber optic transceiver

Compact SMF CWDM QSFP + Optical Transceiver 100G/ps 1270nm AQSFP-100G-LR4

Description:

The Quad Small Form-factor Pluggable ( QSFP or QSFP+) is a compact, hot-pluggable transceiver used for data communications applications. It interfaces a network device motherboard (for a switch, router, media converter or similar device) to a fiber optic cable. It is a industry format jointly developed and supported by many network component vendors. QSFP+ transceivers are designed to support Serial Attached SCSI,100G Ethernet, 20G/40G Infiniband, and other communications standards.The QSFP Transceiver include 100GBASE-SR4 and 100GBASE-LR4 for different applications.

The AscentOptics 100GBASE QSFP+ (Quad Small Form-Factor Pluggable Plus) modules offer customers a wide variety of high-density 100 Gigabit Ethernet connectivity options for data center, high-performance computing networks, enterprise core and distribution layers, and service provider transport applications.

Features

Hot pluggable QSFP28 MSA form factor
Compliant to IEEE 802.3ba 100GBASE-LR4
Up to 10km reach for G.652 SMF
Single +3.3V power supply
Operating case temperature: 0~70^oC
Transmitter: cooled 4x25Gb/s LAN WDM EML TOSA (1295.56, 1300.05, 1304.58, 1309.14nm)
Receiver: 4x25Gb/s PIN ROSA
4x28G Electrical Serial Interface (CEI-28G-VSR)
Maximum power consumption 4.0W
Duplex LC receptacle

Applications

100G Ethernet
Data Centers
100GBASE-LR4 Ethernet Links
Infiniband QDR and DDR interconnects
Client-side 100G Telecom connections

Specification:

Brand:Neuter: OEM
PN: QSFP-100G-SR4-A
Wavelenth: 850nm
Datarate: 100G/ps
Distance: 100M
DDM/DOM: YES
Operating Temperature: 0℃~ +70℃
Voltage Supply: 3.3V
Media: MMF
Connector: MTP/MPO
Application: 40G Ethernet/ 40G Infiniband
Certification: CE/FCC/RoHS/TUV/UL

AscentOptics 40G QSFP+

AQSFP28-100G-LR4

QSFP28 LR4 10km optical transceiver with full real-time digital diagnostic monitoring and pull tab

Competitive advantage:

1	Excellent quality and 3 years warranty
2	Full compatible (CISCO/HP/Extreme/Juniper/H3C…)
3	Competitive pricing
4	OEM/ODM Customized label
5	Keep stock,Fast delivery
